AVX Pro
Automatic Airmix® Spray Gun
The AVX Pro builds on the legendary AVX Automatic Airmix® spray gun. Direct replacement of AVX without any adjustment, it delivers superior finishing, higher reliability, easy service, and lower cost of ownership, all in a lighter, more compact format.
Superior transfer efficiency, with up to 5% extra paint savings
Patented system to secure the fast and the safe positioning of the spray pattern
Outstanding finishing quality
Description
Technical Data
Equipment
Accessories
Kits
Documents & Media
Technologies
Markets
Performance
Airmix® Quality at its best
Airmix® is the perfect fit between quality of finish and productivity. The gun internal diaphragms (1) (2) pre-mix the coating before atomization, optimizing transfer efficiency and improving the final surface finish.
Productivity
High Efficiency, Every Time
Spraying at lower atomization and fluid pressures reduces overspray, VOC emissions, and energy consumption. Compared to the legacy AVX and competing guns, the AVX Pro can save up to 5% in paint usage and up to 10% in rinse fluid.
Sustainability
Reduce downtime
The indexed aircap head (3) and quick disconnect system (4) make cleaning and maintenance fast and effortless, while ensuring the aircap is always repositioned correctly. Additional features—including enhanced cartridges (5), durable carbide seats (6), the integrated NFC chip (7), the opening indicator (8), leak detection, and cartridge lubrication (9)—streamline daily maintenance tasks and significantly reduce technician downtime.
| Designation | Value |
|---|---|
| Maximum Air Pressure (bar) | 6 |
| Maximum Air Pressure (psi) | 87 |
| Trigger Air Pressure (bar) | 3.5 |
| Trigger Air Pressure (psi) | 50 |
| Atomizing Air Inlet | F 1/4 BSPP (fittings M 1/4 NPS/BSP or F 6x8) |
| Pilot Air Inlet | F 1/8 BSPP (fittings F 4x6 or F 2x4) |
| Height (in) | 2.6 |
| Height (mm) | 68 |
| Length (gun only) (in) | 4.1 |
| Width/depth (in) | 1.6 |
| Width/depth (mm) | 45 |
| Maximum Material Pressure (bar) | 240 |
| Maximum Material Pressure (psi) | 3480 |
| Weight (g) | 0.58 |
| Weight (kg) | 0.680 (with lateral base T ) |
| Weight (lbs) | 23.99 |
| Material Inlet Port | 2 x F 1/4 NPSM (fittings M JIC, BSP, NPT) |
| Body Material | Aluminium |
| Maximum Fluid Temperature (°C) | 50 |
| Maximum Fluid Temperature (°F) | 122 |
| Wetted Parts | Stainless steel 303, PTFE |
| Certification | CE-UKCA II2G Ex h IIB T6 Gb X |
| Compatible spray tip | Airmix® Asymmetrical, Airmix® Fine Finish, Airmix® Xtra Fine Finish |
| HVLP Compliant | Yes |
| Seat | Carbide (Option POM-C) |
| Spraying type | Airmix® |
| Designation | Part number | Details |
|---|---|---|
| AVX PRO AUTOMATIC SPRAY GUN, AIRMIX, GT CARTRIDGE | 129693003 | Compatible with circulation in gun (omega) or in base (T) |
| AVX PRO AUTOMATIC SPRAY GUN, AIRMIX, RULON CARTRIDGE | 129693000 | Compatible with circulation in gun (omega) or in base (T) |
| BASE FOR AUTO. AIRMIX GUN, SIDE OUTLETS, T (CIRCULATE THROUGH BASE) | 129692070 | |
| BASE FOR AUTO. AIRMIX GUN, REAR OUTLETS, T (CIRCULATE THROUGH BASE) | 129692080 | |
| BASE FOR AUTOMATIC GUN, REAR OUTLETS, OMEGA, (CIRCULATE THROUGH GUN) | 129693080 | |
| BASE FOR AUTO. AIRMIX GUN,SIDE OUTLETS, OMEGA, (CIRCULATE THROUGH GUN) | 129693070 | |
| BASE AUTO. AIRMIX GUN,CEFLA, SIDE OUTLETS, T (CIRCULATE THROUGH BASE) | 129692090 | |
| AIRCAP ASSEMBLY NX124 KHVLP INDEXED | 132730050 | Without fan width control |
| AIRCAP ASSEMBLY NX24 KHVLP INDEXED | 132730020 | With fan width control |
| Designation | Part number | Details |
|---|---|---|
| ADJUSTABLE FAN WIDTH MANUAL NEEDLE AUTO.GUN (M14x100) | 129253100 | |
| ADJUSTABLE FAN WIDTH CONNECTOR - M14x100 - (F) 1/4 BSPP | 029253002 | |
| MOUNTING SUPPORT DIA.12MM | 049351700 | |
| COMPLETE ATTACHMENT FOR AUTO. GUN ROD D16 + FIXING NUT | 049351000 | |
| SS ELBOW CONN.MM 1/4 NPT 1/2'' JIC | 905210602 | Fluid fitting |
| SS CONNECTOR MM 1/4 NPT 1/2'' JIC | 905210502 | Fluid fitting |
| SS ELBOW CONN.MM 1/4 NPT 1/4 BSP | 905210630 | Fluid fitting |
| SS ELBOW CONN.MM 1/4 NPT | 905210620 | Fluid fitting |
| SS CONNECTOR MM 1/4 NPT 1/4 BSP | 905210530 | Fluid fitting |
| SS CONNECTOR MM 1/4 NPT | 905210520 | Fluid fitting |
| TUBING FITTING (CONTROL) M 1/8 BSP D6MM | 552252 | Trigger air fitting |
| TUBING FITTING (CONTROL) M 1/8 BSP D4MM | 552251 | Trigger air fitting |
| TUBING FITTING (AIR) M 1/4 BSP D8MM | 905121018 | Atomizing air fitting |
| AIR FITTING 'COMMON THREAD' MM 1/4BSP 1/4 BSP/NPS | 22000134 | Atomizing air fitting |
| Designation | Part number | Details | Fittings |
|---|---|---|---|
| KIT NX24 AIRMIX AIRCAP AND MANUAL FAN CONTROL KNOB | 28000180 | ||
| KIT NX24 AIRMIX AIRCAP AND FAN CONTROL AIR FITTING (F) 1/4 BSPP | 28000181 | ||
| KIT AVX PRO RULON BASE LATERAL T (CIRCULATE THROUGH BASE) | 28000170 | replaces 129695000 | Not included |
| KIT AVX PRO GT BASE LATERAL T (CIRCULATE THROUGH BASE) | 28000171 | Not included | |
| KIT AVX PRO RULON BASE REAR T (CIRCULATE THROUGH BASE) | 28000172 | replaces 129695050 | Not included |
| KIT AVX PRO GT BASE REAR T (CIRCULATE THROUGH BASE) | 28000173 | Not included | |
| KIT AVX PRO RULON BASE LATERAL OMEGA (CIRCULATE THROUGH GUN) | 28000174 | replaces 129695100 | Not included |
| KIT AVX PRO GT BASE LATERAL OMEGA (CIRCULATE THROUGH GUN) | 28000175 | Not included | |
| KIT AVX PRO RULON BASE REAR OMEGA (CIRCULATE THROUGH GUN) | 28000176 | replaces 129695150 | Not included |
| KIT AVX PRO GT BASE REAR OMEGA (CIRCULATE THROUGH GUN) | 28000177 | Not included | |
| KIT AVX PRO RULON BASE CEFLA T (CIRCULATE THROUGH BASE) | 28000178 | replaces 129695200 | Not included |
| KIT AVX PRO GT BASE CEFLA T (CIRCULATE THROUGH BASE) | 28000179 | Not included |
-
product-avx-pro-spray-gun_en_GB.pdf
-
3D file of the Automatic airmix AVX Pro with base
Airmix® technology
Let's get in touch-
What is Airmix®?
Airmix® is a technology, invented in 1975 by Kremlin, combines the advantages of airless spraying and air-assisted spraying to deliver high-quality paint application with improved transfer efficiency and reduced product consumption.
-
What are the benefits of using Airmix®?
Airmix® technology enables the application of thicker paint layers to better protect surfaces, without compromising on finish quality. Its benefits include superior finish quality, high transfer efficiency, lower paint consumption, and fast, uniform application.
-
For which types of projects is Airmix® recommended?
Airmix® technology is ideal for industrial applications where a balance between protective thickness and finish quality is required, such as furniture manufacturing, the transportation industry, and rolling equipment, among others.
